Juki MO-6804A Series 3-Thread Industrial Overlock Machine
- 1 year warranty + Free 1 Year machine training in house at Clementi
- Free installation & Delivery Local Islandwide + Demo upon Delivery
- The MO-6800A model of sewing machine has been developed while inheriting JUKI's advanced "dry" technology. JUKI is happy to launch the product which responds to customers' concern about oil stains on the fabric.
Juki MO-6800A Industrial Overlock Machine Features
MO-6804A
Stitch type: 1-needle
Stitch style in the U.S.A.: 504
Lubrication: Semi-dry
Max. sewing speed: 7,000sti/min
Stitch length: 0.6~3.8(4.5)mm
Needle gauge (mm): -
Overedging width (mm): 4.0mm
Differential feed ratio: Gathering 1:2 (Max. 1:4), Stretching 1:0.7 (Max. 1:0.6)
Needle bar stroke: 24.5mm
Inclination angle of the needle: 20°
Needle mechanism: Lower bushing method
Needle: DC×27 (excluding some subclass model)
Max. lift of the presser foot: 7mm (excluding some subclass model)
Max. presser foot pressure: 63.7N (6.5kgf)
Stitch adjusting method: By push-button
Differential-feed adjusting method: By lever (with micro-adjustment)
Weight of the machine head: 27kg
Lubrication: Automatic (The needle bar mechanism and upper looper mechanism do not require lubrication.)
Lubricating oil: JUKI Machine Oil 18 (equivalent to ISO VG18)
Needle cooler: Provided as standard
Needle thread heat remover: Provided as standard
Micro-lifter: Option
For runstitching in general fabric:
MO-6814A
Stitch type: 2-needle
Stitch style in the U.S.A.: 514
Lubrication: Semi-dry
Max. sewingspeed: 7,000sti/min
Stitch length: 0.6~3.8(4.5)mm
Needle gauge (mm): 2.0mm
Overedging width (mm): 2.0, 3.0, 4.0mm
Differential feed ratio: Gathering 1:2 (Max. 1:4), Stretching 1:0.7 (Max. 1:0.6)
Needle bar stroke: 24.5mm
Inclination angle of the needle: 20°
Needle mechanism: Lower bushing method
Needle: DC×27 (excluding some subclass model)
Max. lift of the presser foot: 7mm (excluding some subclass model)
Max. presser foot pressure: 63.7N (6.5kgf)
Stitch adjusting method: By push-button
Differential-feed adjusting method: By lever (with micro-adjustment)
Weight of the machine head: 27kg
Lubrication: Automatic (The needle bar mechanism and upper looper mechanism do not require lubrication.)
Lubricating oil: JUKI Machine Oil 18 (equivalent to ISO VG18)
Needle cooler: Provided as standard
Needle thread heat remover: Provided as standard
Micro-lifter: Option
For runstitching in general fabric:
MO-6816A
Stitch type: Safety stitching
Stitch style in the U.S.A.: 516
Lubrication: Semi-dry
Max. sewingspeed: 7,000sti/min
Stitch length: 0.6~3.8(4.5)mm
Needle gauge (mm): 3.0, 5.0mm
Overedging width (mm): 4.0, 5.0mm
Differential feed ratio: Gathering 1:2 (Max. 1:4), Stretching 1:0.7 (Max. 1:0.6)
Needle bar stroke: 24.5mm
Inclination angle of the needle: 20°
Needle mechanism: Lower bushing method
Needle: DC×27 (excluding some subclass model)
Max. lift of the presser foot: 7mm (excluding some subclass model)
Max. presser foot pressure: 63.7N (6.5kgf)
Stitch adjusting method: By push-button
Differential-feed adjusting method: By lever (with micro-adjustment)
Weight of the machine head: 27kg
Lubrication: Automatic (The needle bar mechanism and upper looper mechanism do not require lubrication.)
Lubricating oil: JUKI Machine Oil 18 (equivalent to ISO VG18)
Needle cooler: Provided as standard
Needle thread heat remover: Provided as standard
Micro-lifter: Option
For runstitching in general fabric:
MO-6843A
Stitch type: 3-needle safety stitching
Stitch style in the U.S.A.: -
Lubrication: Semi-dry
Max. sewingspeed: 7,000sti/min
Stitch length: 0.6~3.8(4.5)mm
Needle gauge (mm): 5.0+2.0mm
Overedging width (mm): 3.0mm
Differential feed ratio: Gathering 1:2 (Max. 1:4), Stretching 1:0.7 (Max. 1:0.6)
Needle bar stroke: 24.5mm
Inclination angle of the needle: 20°
Needle mechanism: Lower bushing method
Needle: DC×27 (excluding some subclass model)
Max. lift of the presser foot: 7mm (excluding some subclass model)
Max. presser foot pressure: 63.7N (6.5kgf)
Stitch adjusting method: By push-button
Differential-feed adjusting method: By lever (with micro-adjustment)
Weight of the machine head: 27kg
Lubrication: Automatic (The needle bar mechanism and upper looper mechanism do not require lubrication.)
Lubricating oil: JUKI Machine Oil 18 (equivalent to ISO VG18)
Needle cooler: Provided as standard
Needle thread heat remover: Provided as standard
Micro-lifter: Option
For runstitching in general fabric:
Cutting-Edge Dry Technology for Achieving a Lubrication-Free Mechanism.
The needle bar mechanism and upper looper mechanism have been re-designed to require no lubrication. The most-advanced dry technologies, such as the special surface treatment applied to the major drive unit and the grease feeding method, contribute to higher durability. The machine does not splash oil after a long-period of use. The grease filler openings are newly provided for the sewing machine on two locations, i.e., one on the upper looper component and the other on the sewing machine frame, thereby improving maintainability.
Oil stains on the sewing product are eliminated.
Oil splashes are substantially reduced to eliminate oil stains on sewing products, thereby upgrading the finished quality.
The frequency of stain removal or re-sewing is reduced.
The machine achieves a practical maximum sewing speed of 7,000sti/min.
Export Packaging:
-
Juki MO6804 Head:32kg -480x340x500mm. = 0.081cbm.
- Clutch Motor: 22kg - 370x300x250mm. = 0.027 cbm.
- Table: 18kg - 1070x570x40mm. = 0.024 cbm.
- Stand: 20kg - 800x580x140mm. = 0.064 cbm.
- Total box-4 cotton boxs
