Juki DDL-7000A-7 Series Direct-drive, Single Needle, Lockstitch Machine with Automatic Thread Trimmer.

Top Choice for Beginners to Professional Use, Producing World Class Quality Finishing.

DDL7000AS
DDL7000AH

 Medium weight model:

- made for stitching of light to medium weight fabrics ; widely used in equatorial weather conditions; stitching 80 to 90% of the outfits for the lifestyle in Singapore’s climate.
- stitch well with commonly available thread sizes. Max size of up to #40 or Tex 70 or V-69 ; depending on the standard of measure of the different countries of origin.

Heavy weight model:

- made for stitching of medium to heavy weight fabrics ; widely used in Tropical weather conditions; stitching 60 to 70% of the outfits for the lifestyle in Shanghai ; Winter climate conditions.
- greater application in stitching of Denim; Jeans ; Canvas, Leathers ; Bags ; Sofa’s and Clothing Alteration provider.
- stitch well with Thick threads. Max size of up to #20 or Tex 135 or V-92 ; depending on the standard of measure in the different countries of origin.

1 Year Warranty + Free 1 Year Machine Training In-house at Clementi
Free Installation & Delivery Local Islandwide + Demo upon Delivery

• Energy-saving servomotor is installed in the direct-drive style.

• The thread take-up lever which provides a wider sewing range is adopted.
• Needle bar stroke is 35 mm,With this feature, the sewing machine is able to sew many different types of materials ranging from light-weight ones to medium-weight denim.

Export Packing Dimension
Head: 835 x 275 x 440 mm; Gross Wt: 38.95kg
Table: 1070 X 540 X 40mm; 26kg
Stand: 800 X 600 X 200mm; 26kg.

	Covered by 1 year Ban Soon Care inclusive 365 days of free consulting, in-house training at www.Sewing.sg, after-sales services upon purchase new sewing machines with Ban Soon Sewing Machine Pte Ltd.
	Research & Development: Consult us with the possibility of each sewing machines, embroidery machines, overlock machines, ScanNCut machines and coverstitch machines that you can achieve. Show us the sewing patterns result that you desire, we will research and provide you the easiest solutions and the tools for a smooth  sewing experience.
	Trade-in options available and replace your old machines with upgrade program.
	Experience all the demo & display machines at our showroom - Bring your dedicated materials and test drive it. We will recommend the most suitable machine for you based on your profile [not the most expensive machines].
	Flexible payment method supported - Cash, PayNow [Recommended - Paperless] , PayLah [Recommended - Paperless] , Bank Transfer, NETS, Cheque Credit/Debit Cards, Installment*, and etc.
	Sewsol Equipment Sharing available - Wide range selection of Sewing Machines, Embroidery Machines, Software, ScanNCut Machine, Serger or Overlock Machines, Coverstitch Machines, Cylinder Bed Unison Feed Machines for Leather*, Industrial Machines etc.
	Warranty and Servicing from Experience in-house Professional Technicians.

Contents

• Juki DDL-7000A Series High Speed Lockstitch Machine Highlights
• Juki DDL-7000A Series High Speed Lockstitch Machine Features
• Juki DDL-7000A Series High Speed Lockstitch Machine Accessories and Parts
• Juki DDL-7000A Series High Speed Lockstitch Machine Review
• Juki DDL-7000A Series High Speed Lockstitch Machine Price and Where to find us
• Juki DDL-7000A Series High Speed Lockstitch Machine Service and Repair
• Juki DDL-7000A Series High Speed Lockstitch MachineSewing Lessons and Classes
• Juki DDL-7000A Series High Speed Lockstitch Machine Manufacturers, Suppliers, Vendors and Wholesale

Juki DDL-7000A Series High Speed Lockstitch Machine Highlights

 

• The direct drive system has been adopted.
• Both the control box and the operation panel are integrated with the machine head.
• Dramatically advanced availability for the material.

Juki DDL-7000A Industrial Lockstitch Machine Features

Application

• Direct Drive, Digital, Semi-Dry Lubrication; Light-Medium Weight
• Direct Drive, Digital, Semi-Dry Lubrication; Heavy Weight
• Max. Sewing Speed
• 5,000 Stitch/Min
• Max. Stitch Length - 5mm

Needle Bar Stroke

35mm

Needle

Needle Type: DBX1
Applicable Size: 9/65 to 18/110.

Lift of the Presser Foot

By Hand: 5.5mm
By Knee: 13 mm

Energy-saving servomotor is installed in the direct-drive style

The energy-saving and highly efficient servomotor is installed in the direct-drive style to transmit power without loss to the sewing machine, thereby providing improved responsiveness, quicker start-up and increased needle penetration force.

The compact-sized control box and operation panel

Both the compact-sized control box and the operation panel are integrated with the machine head. The machine is provided as standard with the operation panel.

The operation panel is equipped box with ease with many different functions.

The power switch is built into the control box, making it easy to install the machine. Connection to the external output terminal is also very easy. The USB port is located below the control panel.

Operation Panel



USB Port & Power Switch



Responsiveness to the material is improved to sew many different types of materials.

The thread take-up lever which provides a wider sewing range is adopted.
Needle bar stroke is 35 mm, with this feature, the sewing machine is able to sew many different types of mat

Provided as standard with LED lighting

Since the LED lights cast their light exactly downward to illuminate the needle entry area from the right and left sides of the needle bar, sewing work can be carried out more easily as compared with the use of light from one direction. In addition, the illuminance of the LED lights can be adjusted in five steps and can be used as an auxiliary light for work.



Highly-functional touch-back switch

JUKI's sewing machine which is provided with a thread trimmer is also provided as standard with the renowned needle breakage preventing function. The main shaft angle control works to prevent needle breakage even when the touch-back switch is used to perform reverse feed stitching. The height of the touch-back switch is adjustable according to the items to be sewn.



Option

Long Pitch Kit (7mm for H type): 40234068
*Max. Sewing Speed will be 3,500 Stitch/Min

Specifications for Juki DDL7000A 7

Model name	DDL-7000AS-7	DDL-7000AH-7
Application	Light to medium weight	Heavy weight
Max. sewing speed	5,000 sti/min*	4,000 sti/min*
Max. stitch length	5mm
Presser foot	By hand: 5.5mm, By knee: 13mm
Lubricating oil	JUKI Machine Oil 7 (equivalent to ISO VG7)
Needle	DB × 1 (#14) #14~#18	DP × 5 (#21) #20~#23
Power consumption	210VA
Weight of machine head	34kg (include motor, control box, cover)
Outside dimensions of package (mm)	833 × 278 × 459

* sti/min is the abbreviation for "stitches per minute"

Export Packing (Head only): 840 x 240 x 445mm

Downloads:

Download Juki DDL-7000A Brochure

Juki DDL-7000A Series High Speed Lockstitch Machine Accessories and Parts

High Mobility Products, please click:

• 9.5mm Height Bobbin (Made in Japan)
• Bobbin Case
•  Industrial Sewing Machine Oil (1 Litre)

Ban Soon Care Additional Service on Testing your Bobbin Case Tension
